Portable bus processing machine hydraulic punching machine

1. Connect the oil pump and the working head with a quick connector
2. Choose the corresponding upper and lower molds, first install the upper mold, and then the lower mold. When installing the upper mold, first unscrew the positioning screw out of a certain position and then install the lower mold. Be sure to put it in place, and then tighten the positioning screw to work.
3. Put the workpiece, step on the footswitch until the work is completed, step on the footswitch in the opposite direction, the punching upper die will automatically return, such as when punching thin metal plates, be sure to insert the return pad into the return rack And the middle of the workpiece, otherwise the workpiece will be stuck in the upper die.

Portable bus processing machine hydraulic cutting machine

1. Connect the male connector to the pump female connector first, and then tighten it.
2. Put the cut product on the knife edge.
3. Step on the footswitch to cut the blade closer to the product being cut.
4. Step on the footswitch in the opposite direction, the blade will automatically reset

Hydraulic bending machine

1. Connect the male connector to the pump female connector first, and then tighten it.
2. Put the folded product on the bending machine.
3. Step on the footswitch to make the angle mold approach and bend the product to be bent.
4. Step on the footswitch in the opposite direction and the angle mode will automatically reset.

Transformer manufacturing equipment, foil winding machine, winding machine.
